Electronic Dosing Pump

Name: Electronic Dosing Pump
Brand: RELIABLE ENGINEERS
Price: 4000 INR
Availability: InStock

4000 INR/Piece

Get a Price/Quote

Product Details:

Max Suction 2 meters
Caliber 4 mm to 8 mm
Head Size up to 10 Bar
Inlet/Outlet 1/4 BSP
Features Compact, Corrosion Resistant, Precise Dosing
Frequency 50-60 Hz
Mounting Type Wall or Base Mount
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Electronic Dosing Pump Price And Quantity

Price 4000 INR/Piece
Minimum Order Quantity 1 Piece

Electronic Dosing Pump Product Specifications

Fuel Type N/A (Electric)
Control System Manual Stroke Regulator/Digital Controller
Speed Fixed/Adjustable (based on controller type)
Theory Electromagnetic Dosing
Flow Rate 0.5 to 6 LPH (Liters Per Hour)
Standard IP65 Protection
Application Other
Discharge Pressure Up to 10 Bar
Priming Automatic
Power 10-15W
Voltage 230V AC / 50 Hz
Usage Other
Capacity 0.5-6 LPH
Material PP housing, Teflon diaphragm, SS fasteners
Working Temperature 5C to 50C
Suction Type Self-priming
Frequency 50-60 Hz
Noise Level Low Noise Operation
Seals Type PTFE or Viton
Mounting Type Wall or Base Mount
Pump Type Electronic Dosing Pump
Pressure Max 10 Bar
Max Suction 2 meters
Caliber 4 mm to 8 mm
Structure Diaphragm Pump
Head Size up to 10 Bar
Inlet/Outlet 1/4 BSP
Features Compact, Corrosion Resistant, Precise Dosing

Diaphragm Material Teflon-coated EPDM
Compatible Fluids Acids, Alkalis, Disinfectants, Chlorine, Flocculants, Anti-scalant
Insulation Class Class F
Control Input Pulse/4-20 mA optional
Power Cord Length 1.5 meters
Protection Class IP 65
Display LED/Manual Adjustment knobs
Weight Approx. 2 kg

Electronic Dosing Pump Trade Information

Supply Ability 10 Piece Per Week
Delivery Time 7 Days

Product Description

Faeture

Splash-proof enclosure
Auto resetting fuse
Double ball NRV with PTFE seals
Splash proof enclosure
Built in air release valve (ARV)
PTFE diaphragm for longer life
Adjustable frequency (up to 130 spm)
Compact and lightweight

MODEL	EDP-6/4	EDP-10/4
CAPACITY	6 LPH	10 LPH
PRESSURE	4 KG/CM2	4 KG/CM2
TYPE	SOLENOID OPERATED ELECTRONIC DOSING PUMP	SOLENOID OPERATED ELECTRONIC DOSING PUMP
POWER SUPPLY	230V,50 Hz,1 PHASE	230V,50 Hz,1 PHASE
POWER CONSUMPTION	20 WATT	20 WATT
FLOW ADJUSTMENT	MANUAL ADJUSTABLE(0-130 SPM)	MANUAL ADJUSTABLE(0-130 SPM)
SUCTION	1 METER	1 METER
END CONNECTION	6/8 mm	6/8 mm
TEMP	45 C max	45 C max

Standard Accessories

SUCTION & DISCHARGE TUBE-LDPE/PTFE/PU(3 METER)
FOOT VALVE CUM STRAINER-PP/PTFE(1 NOS)
ANTISYPHONING VALVE-PP/PTFE(1 NOS)
TUBING SIZE-LDPE/PTFE/PU(6/8 MM)

Precision Chemical Dosing

Designed for exact dosing needs, this electronic pump delivers highly accurate flow rates ranging from 0.5 to 6 LPH. Its Teflon-coated EPDM diaphragm and advanced PTFE or Viton seals ensure chemical compatibility, minimizing leaks and maintenance. The combination of automatic priming and precise stroke regulation guarantees reliable operation in critical dosing applications.

Versatile Fluid Compatibility

Engineered to handle a wide selection of chemicals, including acids, alkalis, disinfectants, chlorine, flocculants, and anti-scalants, this dosing pump is ideal for water treatment plants and various industrial processes. Its corrosion-resistant materials prolong service life while supporting safe and effective dosing across diverse applications.

User-Friendly Operation & Flexible Installation

With both LED display and manual adjustment knobs, the pump offers intuitive control, whether you prefer digital or manual settings. Wall or base mounting options provide flexibility for different installation environments, and its low noise operation ensures minimal disruption in the workspace.

FAQ's of Electronic Dosing Pump:

Q: How does the automatic priming feature of the pump work?

A: The pump's automatic priming function enables it to self-prime quickly, ensuring that air is expelled from the system before dosing begins. This reduces manual intervention and helps maintain dosing accuracy right from startup.

Q: What types of fluids can the electronic dosing pump handle safely?

A: This pump is compatible with a range of aggressive chemicals, including acids, alkalis, disinfectants, chlorine, flocculants, and anti-scalants, thanks to its Teflon-coated diaphragm and corrosion-resistant construction.

Q: When should I use this dosing pump in my process?

A: You should use this electronic dosing pump whenever precise and consistent chemical dosing is required, such as in water treatment, chemical processing, or industrial disinfection routines.

Q: Where can the pump be installed and mounted?

A: The pump is designed for versatile installation, allowing for wall or base mounting in various environments, including industrial, laboratory, or water treatment applications.

Q: What is the benefit of having both LED display and manual knobs?

A: The dual control system lets users easily adjust dosing rates either digitally via the LED display or manually with knobs, providing flexible and convenient operation for different preferences.

Q: How does the pump ensure safety when handling corrosive chemicals?

A: Constructed with corrosion-resistant materials like a Teflon-coated diaphragm, PP housing, and stainless steel fasteners, the pump minimizes risk of chemical attack and extends operational life.

Q: What is the process for adjusting the flow rate or pressure?

A: You can regulate flow and pressure by using the manual stroke regulator or the digital controller, depending on the model. Adjustment is straightforward, enabling precise control tailored to your application needs.
